Stanley 322Joining and surfacing parts subject to service in marine environments and seawater.
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Very high strength aluminum bronze electrode with excellent wear resistance.
• Universal electrode safely repairs all grades of aluminum bronzes.
• Resists corrosion, cavitation, erosion, and metal to metal wear.
• Also excellent for overlays on cast irons, steels and copper. |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
TYPICAL MECHANICAL PROPERTIES :
Undiluted Weld Metal Maximum Value Up to:
Tensile Strength 89,000 Psi ( 61 MPa )
Yield Strength 59,000 Psi ( 41 MPa )
Elongation 23 %
Hardness Brinell 148, Rockwell B82
APPLICATIONS :
Joining and surfacing parts subject to service in marine environments and seawater.
MICROSTRUCTURE :
Complex alpha matrix with kappa compound phases and some retained beta phase.
RECOMMENDED CURRENT :
DC reverse ( + )
WELDING POSITIONS :
Flat.
WELDING TECHNIQUES :
Preheat is not required. Maintain a short arc gap. Clean slag thoroughly between passes. |
|
