Stanley 608Wear facing electrode for impact and moderate abrasion
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
Wear facing electrode for impact and moderate abrasion
- Excellent welding characteristics.
- Deposits are very crack resistant.
- Multiple layers are easily applied for thick build-ups.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
APPLICATIONS:
Especially suited for metal to metal wear applications involving steel, manganese steel and cast iron.
MICROSTRUCTURE:
Martensite with some carbides.
FLUX COLOR: Grey
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
H a r d n e s s |
Maximum Value Up to:
Vickers 650
Rockwell C58-60 |
RECOMMENDED CURRENT: DC Reverse (+/-), or AC
RECOMMENDED AMPERAGE SETTINGS:
| Diameter (mm) |
1/8(3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Minimum Amperage |
80 |
110 |
140 |
| Maximum Amperage |
120 |
160 |
180 |
WELDING POSITIONS: Flat, Horizontal
DEPOSITION RATES:
Diameter
(mm) |
Length
(mm) |
Weldmetal/
Electrode |
Electrodes per lb
(kg) of Weldmetal |
Arc Time of
Deposition
min/lb (kg) |
Amperage
Setting |
Recovery
Rate |
| 1/8 (3.25) |
14" (350) |
1.1oz (31g) |
14 (30) |
23 (50) |
120 |
180% |
| 5/32 (4.0) |
14" (350) |
2.7oz (76g) |
6 (14) |
17 (37) |
175 |
180% |
| 3/16 (5.0) |
14" (350) |
4 oz (112g) |
4 (9) |
13 (29) |
250 |
180% |
WELDING TECHNIQUES:
No preheat required. Remove all loose and foreign matter. Deposit stringer or weave beads using a short arc length.
ELECTRODE PACKAGING & DIMENSIONS:
| Diameter(mm) |
1/8 (3.25) |
5/32 (4.0) |
3/16 (5.0) |
| Length (mm) |
14" (350) |
14" (350) |
14" (350) |
| Electrodes / lb |
8 |
6 |
5 |
| Electrodes / kg |
18 |
13 |
11 |
|
|
