Stanley 206

Extremely smooth running alloy grade 6 cobalt electrode. Self releasing slag.

Overview
Specifications
Email to a Friend
Extremely smooth running Alloy 6 Cobalt electrode
  • Controlled weld bead allows for easy edge buildups.
  • Slag is self releasing.
  • Weld deposits are unusually fine rippled and uniform.
  • Available bare as product code Stanley 206 TIG
  • Special technology also performs on AC current.
Overview
Specifications
Email to a Friend
APPLICATIONS:
For moderate abrasion resistance combined with resistance to corrosion, erosion and thermal shock.

MICROSTRUCTURE:
Cobalt based austenite with some carbides and other complex phases.

FLUX COLOR: Grey

TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
H a r d n e s s
Room Temperature: 68oF (20oC)
Work Hardened
Elevated Temperatures:
750oF (400oC)
1110oF (600oC)
1475oF (800oC)
1620oF (900oC)		 Maximum Value Up to:

Rockwell C45
Rockwell C55

Rockwell C32
Rockwell C28
Rockwell C22
Rockwell C20

RECOMMENDED CURRENT: AC or DC Reverse (+)

TEMPERATURE RANGES:
Diameter (mm) 3/32(2.5) 1/8(3.25) 5/32(4.0)
Minimum Amperage 65 80 100
Maximum Amperage 85 110 130

WELDING POSITIONS: Flat, Horizontal

RECOMMENDED AMPERAGE SETTINGS:
Diameter
(mm)		 Length
(mm)		 Weldmetal/
Electrode		 Electrodes per lb
(kg) of Weldmetal		 Arc Time of
Deposition
min/lb (kg)		 Amperage
Setting		 Recovery
Rate
3/32 (2.5) 14" (350) .80oz (22g) 20 (44) 19 (42) 75 130%
1/8 (3.25) 14" (350) 1.2oz (33g) 13 (29) 14 (31) 95 130%
5/32 (4.0) 14" (350) 1.56oz (44g) 10 (22) 11 (24) 155 130%

WELDING TECHNIQUES:
Preheat massive parts to 570oF (300oC). Minimize amperage during welding.

ELECTRODE PACKAGING & DIMENSIONS:
Diameter(mm) 3/32(2.5) 1/8 (3.25) 5/32 (4.0)
Length (mm) 14" (350) 14" (350) 14" (350)
Electrodes / lb 17 10 6
Electrodes / kg 37 22 13
