Stanley 325AC-DC tin bronze electrode can be used as an electric brazing rod
 |
|
Overview |
|
Specifications |
|
Email to a Friend |
|
AC - DC tin bronze electrode can be used as an electric brazing rod
- Bronze electrode that works very well on AC current.
- Excellent for joining copper base alloys not only to themselves but to stainless steel, cast iron, and steels.
|
|
Overview |
|
Specifications |
|
Email to a Friend |
|
APPLICATIONS:
For joining a wide variety of copper base alloys to themselves and to steels and cast irons.
MICROSTRUCTURE:
A multi phase copper base structure with complex eutectoids.
FLUX COLOR: Dark Brown
TYPICAL MECHANICAL PROPERTIES:
Undiluted Weld Metal
Tensile strength
Yield strength
Elongation
H a r d n e s s
|
Maximum Value Up to:
50,000 PSI (340 N/mm2)
30,000 PSI (210 N/mm2)
18%
Brinell 105, Rockwell B78 |
RECOMMENDED CURRENT: DC Straight (-) or AC
TEMPERATURE RANGES:
| Diameter (mm) |
3/32 (2.5) |
1/8(3.25) |
5/32 (4.0) |
| Minimum Amperage |
75 |
100 |
120 |
| Maximum Amperage |
100 |
135 |
160 |
WELDING POSITIONS: Flat
DEPOSITION RATES:
Diameter
(mm) |
Length
(mm) |
Weldmetal/
Electrode |
Electrodes per lb
(kg) of Weldmetal |
Arc Time of
Deposition
min/lb (kg) |
Amperage
Setting |
| 3/32 (2.5) |
14" (350) |
.6oz (17g) |
27 (59) |
54 (118) |
85 |
| 1/8 (3.25) |
14" (350) |
.7oz (20g) |
22 (48) |
54 (118) |
120 |
| 5/32 (4.0) |
14" (350) |
1oz (28g) |
15 (32) |
20 (45) |
140 |
WELDING TECHNIQUES:
Remove all surface contamination from weld area. Maintain a short arc gap and fill in craters prior to extinguishing the arc.
ELECTRODE PACKAGING & DIMENSIONS:
| Diameter(mm) |
3/32 (2.5) |
5/32 (4.0) |
3/16 (5.0) |
| Length (mm) |
14" (350) |
14" (350) |
14" (350) |
| Electrodes / lb |
22 |
14 |
9 |
| Electrodes / kg |
48 |
31 |
20 |
|
|
